An electronic controlled float switch and strainer assembly designed to sense and remove free air before it can enter the flow meter. Efficiently removing air from the truck delivery while minimizing the amount of the residual product released from the system. The float switch has a wide specific gravity range for product use, and requires NO annual maintenance.

A relay controller is required to actuate the solenoid vent when air is present within the air eliminator vessel, such as the TCS 3000 electonic register. Also required is a valve downstream of the meter to stop flow until air has been removed. Accuracy better than 0.2% of maximum allowed error during product depletion (split compartment) testing.

SPECIFICATIONS

Size: 2", 3" & 4"
Voltage: 12 VDC
Rating: Class 1, Division 2
Type: SP, SPD & SSD
Pressure: 150 PSI (10.5 BAR)
Temperature: -40F to 160F (-40C to 71C)
Material: Aluminum, Ductile Iron & Stainless Steel (SSD 2" only)
Seals: FKM, PTFE & Simriz
Strainer Mesh: 40 Mesh (Stainless Steel)













Compatible Meters

  • 682 Piston Meter

    The TCS 682 reciprocating piston flow meter combines outstanding accuracy (0.1% of flow rate) with one of the widest turndown ratios in the industry (...
  • TCS 700-20

    The 700 2" rotary flow meter is engineered to meter liquid at up to 100 GPM (380 LPM).
  • TCS 700-25

    The 700 2" rotary flow meter is engineered to meter liquid at up 150 GPM (567 LPM).
  • TCS 700-30

    The 700 3" rotary flow meter is engineered to meter liquid at up to 200 GPM (760 LPM).
  • TCS 700-35

    The 700 3" rotary flow meter is engineered to meter liquid at up to 300 GPM (1,135 LPM).
  • TCS 700-40

    The 700 4" rotary flow meter is engineered to meter liquid at up to 500 GPM (1,893 LPM).
