The TCS 3000 features the industry's first and most complete built-in inventory program.

3000 integration inventory largeVIEW DIGITAL OR MANUAL INVENTORY LEVELS

  • DIGITAL - Actual Real-Time Tank Readings
  • MANUAL - Reset Levels at the Rack & Subtract Deliveries

CALIBRATE TANKS

The TCS 3000 offers 4 tank calibration methods for tracking inventory. For both the Quasi linear and Polynomial methods, strapping charts can be generated while initially filling the tank, imported via excel, or manually inputted.

  • MANUAL - No tank level gauge - Simply set the tank size, name, and assign it to a product.
  • EXTERNAL - Requires tank level gauge - Shows level in percent using the inventory capacity.
  • QUASI LINEAR - Requires a tank level gauge - Shows linear interpolation between calibration points.
  • POLYNOMIAL - Requires a tank level gauge - Shows points between smooth shape tank calibration points - Auto-calibration of tank strapping charts

IMPROVE ROUTING DECISIONS

  • Know When Inventories Are Too Low to Complete Deliveries
  • Send Inventory Levels Back to Dispatcher via TCS HUB
  • Locate Delivery & Inventory when GPS Is Enabled & Using TCS HUB

TECHNOLOGY

  • 4-20mA Current Input
  • Compatible with Float, Ultrasonic, Pressure, and Radar Sensor Technologies
  • Can Upload Tank Strapping Charts from an Excel Spreadsheet
  • Up to Six (6) Product Tank Inventories Available
  • Change Product Tank Assignment By Shift
  • Visual Color Graphic Level Indication
  • Quick ‘Fill Up’ Manual Inventory Reset Button
  • Printed Inventory Reports
