Dual Capsule Meter
TCS 700-60SPA
Dimensions
A
400mm / 15.75in
B
429.9mm / 16.93in
C
348.0mm / 13.70in
D
170.0mm / 6.69in
A
400mm / 15.75in
B
426.7mm / 16.80in
C
415.0mm / 16.34in
D
277.6mm / 10.93in
Flow Rates
Dual Capsule Meter
LPM
200-2800
USG
52-740
TCS 700-60SPA
LPM
303-3028
USG
80-800
Flanges
Dual Capsule Meter
Connection
4" ANSI150 RF
TCS 700-60SPA
Connection
4" ANSI150 RF
Materials of Construction
Dual Capsule Meter
Housing
Ni-Resist II
Rotor
Aluminum
Vanes
Carbon Graphite
Bearings
Stainless Steel
Seals
Buna N or FKM
Internal Hardware
Stainless Steel
TCS 700-60SPA
Housing
Anodized Aluminum
Rotors
Anodized Aluminum
Bearing Plates / Bearings
Ni-Resist II / Carbon Graphite
Seals
FKM
Internal Hardware
Stainless Steel
